5 95 Small Line Ball Valve Pump

The 5 80 & 95’s 7″ delivery cylinders combined with the Millennium Series manifold, handle both course and high sack structural 1/2″ mixes, making them the perfect choice for residential, commercial, and large slurry backfill jobs.

Category:

Description

Specification

Maximum Output 100 yph 76 cmh
Delivery Pressure 1100 psi 76 bar
Delivery Cylinder 7 in 178 mm
Stroke 36 in 914 mm
Strokes/Minute 56
Engine Power 124 hp 91 kw
Hopper Capacity 6 cu ft .17 cu mtr
Outlet 4 in 100 mm
Control System Electric/Hydraulic
Hydraulic Capacity 85 gals 338 l
Weight 5680 lbs 2576 kg
Length 175 in 445 cm
Width 70 in 178 cm
Height 82 in 208 cm
