5 25 Small Line Ball Valve Pump

The OLINPUMP 5 25 is the only 1/2” minus hydraulic Ball Valve concrete pump that is exempt of CARB and AQMD permitting. The 48 HP Deutz 3 cyl diesel engine combined with simple, efficient hydraulics, yields over 30 YPH production rates, and can push as far and as high as any pump on the market!!

Category:

Description

Maximum Output 40 cyh 30 cmh
Delivery Pressure 750 psi 52 bar
Delivery Cylinder 5 in 127 mm
Stroke 12 in 305 mm
Strokes/Minute 133
Engine Power 48hp 36 kw
Hopper Capacity 6 cu ft .17 cu mtr
Outlet 4 in 100 mm
Control System Electric/Hydraulic
Hydraulic Capacity 78 gal 295 l
Weight 4100 lbs 1977 kg
Length 163 in 414 cm
Width 70 in 178 cm
Height 82 in 208 cm

Additional information

Brand

Olinpump

Outlet

5 inches
